Casio CE-2350 - Main PCB Component List (Continued)

30
N Item Code No. Parts Name Specification Ver. Q M
FOB Japan
N.R.Yen
Unit Price
R
X2 2801 8932 Ceramic oscillator CST4.19MGW 1 75 A
N C6 2807 2231 Electrolytic capacitor RE2-50V470M-T2 1 20 22 C
N C9 2807 2238 Electrolytic capacitor RE2-50V010M-T2 1 20 13 C
N C8 2807 2245 Electrolytic capacitor RE2-25V331M-T2 1 10 36 C
N C2 2807 2252 Electrolytic capacitor RE2-35V102M 1 110 C
N C1 2807 2259 Electrolytic capacitor RE3-50V332M 1 310 C
N C21 2807 2770 Ceramic capacitor HE40TJCH120J 1 20 10 X
N C13~18,32
C34~40
2813 0217 Ceramic capacitor HE50TJYB102K 14 20 4 X
N C20 2818 3881 Ceramic capacitor HE40TJCH150J 1 20 10 X
N C43 2818 3882 Ceramic capacitor HE80TJYB472K 1 20 7 X
C33 2819 0735 Ceramic capacitor HE40TJYB471K 1 20 4 X
C25 2819 0743 Ceramic capacitor HE40TJYB101K 1 20 6 X
C3,5,11,12,19
C22~24,26~28
C31,42
2819 5542 Ceramic capacitor HE12TJYB103K 13 10 X
C30,41 2820 3233 TF capacitor ECQ-V1H-104-JZW 2 22 X
C10,29,44 2820 3713 TF capacitor ECQ-B1H103KFW 3 20 7 X
C4 2830 5729 Mylar capacitor 50F2S563J 1 14 X
F1 3000 6559 Fuse 237 315 1 5 52 A
L1 3018 0854 Inductor MCDR1419-681K 1 5 52 X
BUZZER 3122 1589 Sounducer PKM22EPP-2002 1 65 C
CN5 3500 3355 Pin ass'y 3P IL-G-3P-S3T2-E 1 7 C
CN3 3500 5831 PCB connector 52045-2045 1 50 C
CN4 3500 7122 Pin ass'y 53253-0310 1 20 8 C
N CN2 3501 5460 FFC Connector 52045-2845 1 5 93 C
N CN6 3501 5474 FFC connector 52045-2245 1 5 78 C
CN1 3510 2680 Pin ass'y 2P 5277-02A 1 20 15 C
F2 3631 0328 Fuse UL-TSCR-0.8A 1 75 A
F1 3640 2331 Fuse clip UF-0033 2 10 8 X
3750 1272 Heat sink OSH-1625-SPL 1 70 X
N 4308 1067 PCB E259-1
(without components)
E211747-1 1 310 X
5041 5155 Screw (+) 3X8 ZMC-3 1 50 2 X
