Casio CFX-9850G User Manual

42
Chapter 3: Commands and Programming
Stat Point Raw Data
Post-processing Result
x
&n x minX maxX
1 1.0, 1.2, 1.1, 1.3 1.15 0.11 1.0 1.3
2 2.3, 4.0, 2.6, 3.2 3.03 0.65 2.3 4.0
3 3.5, 2.6, 3.7, 4.8 3.65 0.78 2.6 4.8
4 3.7, 4.2, 4.5, 5.2 4.4 0.54 3.7 5.2
5 4.8, 5.6, 4.3, 5.4 5.03 0.51 4.3 5.6
'
Cleared
'
List1
'
List2
'
List3
To CFX-9850G
'
List4
Channel Setting Example
The following two examples are for analog channels.
{1,4,2} 1 = CHANNEL SETUP
4 = SONIC
2 = Meters
{1,1,3,1} 1 = CHANNEL SETUP
1 = CH1
3 = Current
1 = Post-processing (first derivative)
The following two examples are for the digital output channel.
{1,6,1,10} 1 = CHANNEL SETUP
6 = DIG OUT
1 = One output data element
10 = Digital pattern of 1010 for output element
{1,6,5,2,4,6,8,10} 1 = CHANNEL SETUP
6 = DIG OUT
5 = Five output data elements
2,4,6,8,10 = Digital pattern of 0010, 0100, 0110,
1000, 1010 for output element
