Chapter 3: Commands and Programming
DATA RANGE SETUP Examples
{5,1,2} 5 = DATA RANGE SETUP
1 = Transfer data from CH1
2 = Filtered d
2
/d t
2
data (when filtering is turned on
with Command 1)
{5,2,0,256,300} 5 = DATA RANGE SETUP
2 = Transfer data from CH2
0 = Filtered raw data (when filtering is turned on
with Command 1)
256 = Starting sample number
300 = Ending sample number
Command 6 - MULTIMETER MODE SETUP
Command 6 specifies a channel for multimetering. Only one channel (the
one you specify) is enabled in the Multimeter Mode at a time.
Syntax
{6, Set/Reset, Channel Select, Operation}
• Pressing the [MODE] key and entering the Multimeter Mode makes it
possible to use the data analyzer as a stand-along measuring instru-
ment without commands from a graphic scientific calculator.
Set/Reset Parameter
This parameter executes a Multimeter Mode set or reset operation. The initial
default for this parameter is 1.
0 Returns to the Communications Mode
1 Enters the Multimeter Mode
The following points apply whenever the data analyzer is in the Multimeter
Mode.
• Command 6 with a set/reset parameter of 0 is the only valid command
accepted by the data analyzer.
• The default sample time is approximately 1 second.
• Sampling results appear on the display, but are not sent to a connected
calculator.
Channel Select Parameter
This parameter selects a channel for measurement.
1 Channel 1 (CH1)
2 Channel 2 (CH2)
3 Channel 3 (CH3)
