20070201
k Drawing a Dynamic Graph Locus
Description
Turning on the Dynamic Graph locus setting on the Setup screen lets you overlay a graph
drawn by changing the coeffi cient values.
Set Up
1. From the Main Menu, enter the DYNA mode.
2. Make V-Window settings.
Execution
3. On the Setup screen, select “On” for “Locus”.
4. Use the cursor keys to select the function type on the built-in function type list.
5. Input values for coeffi cients, and specify which coeffi cient will be the dynamic variable.
6. Specify the start value, end value, and increment.
7. Specify Normal for the draw speed.
8. Draw the Dynamic Graph.
5-8-3
Dynamic Graphing
