k Angle Units
To change the angle unit of an input value, fi rst press K 6 (g )5 (ANGL). On the
function key menu that appears, select “
°
”, “r”, or “g”.
• Be sure to specify Comp for Mode in the Setup screen.
Example Operation
To convert 4.25 rad to degrees:
243.5070629
!m (SET UP)cccccc 1 (Deg)J
4.25 K 6 (g )5 (ANGL)2 (r)w
47.3° + 82.5rad = 4774.20181°
47.3 + 82.5 K 6 (g )5 (ANGL)2 (r)w
2°20´30˝ + 39´30˝ = 3°00´00˝
2 K 6 (g )5 (ANGL)4 (° ’ ”) 20 4 (° ’ ”) 30
4 (° ’ ”)+ 0 4 (° ’ ”) 39 4 (° ’ ”) 30 4 (° ’ ”)w
5 (
° ’ ”
)
2.255° = 2°15´18˝
2.255 K 6 (g )5 (ANGL)6
(g )3 (' DMS)w
2-4-3
Function Calculations
# Once you specify an angle unit, it remains
in effect until you specify a different one.
The specifi cation is retained even if you turn
power off.
