Casio DT-940 User Manual

― 60 ―
12
3456789101112
FINAL ASSY
10258141 COVER/MAIN BATT RJC502520-001V02 11 11111 1 1 C
10258686 COVER/MAIN BATT RJC502520-002V02 1 1 1 C
10251586 COVER/SUB BATT RJC503133*001V01HK 1 1 11111 1 1 C
10251585 COVER/SUB BATT RJC503133*002V01HK 1 1 1 C
N 42 10394158 LASER MODULE MDL-1001 1 1 A
N 43 10390309 LS HOLDER RJC505618-001V01 1 1 X
44 10017815 SCREW HA310076-003 3 3 X
N 45 94834212 SCREW RJC502612-001V01T 2 2 X
3 10215467 TAPE/B RJC501976-001V01 2 2 2222222 2 3 3 C
4 10215464 TAPE/A RJC501975-001V01 1 1 1111111 1 1 1 C
5 10241535 SCREW/FLAT HEAD RJC502694-001V03 2 22 22 2 X
6 63357030 SCREW/FLAT HEAD A33953-21 3 3 3333333 3 3 3 X
7 10245916 SCREW/Y-TOP RJC500914-008V02 6 6 6666666 6 6 6 C
UPPER CASE BLOCK
10251575 CASE ASSY/UPPER RJC503129*001V01HK 1
11
C
10251576 CASE ASSY/UPPER RJC503129*002V01HK 1 11 11 1 C
10251579 CASE ASSY/UPPER RJC503129*003V01HK 1 1 1 C
9 10279454 LCD ASSY RJC503306*001V01HK 111111111 1 1 1 A
10 10230502 KEY ASSY RJC502529*001V01 1 1 1111111 1 1 1 C
11 10243922 PCB ASSY/KEY RJC502510E101V01HK 111111111 1 1 1 C
12 10232024 FFC/KEY RJC502590-001V01 1 1 1111111 1 1 1 C
13 10017815 SCREW HA310076-3 2 2 2222222 2 2 2 X
N 46 69402071 SCREW/FLAT TAPPING HA310076-5 444444444 4 4 4 X
Components for Item #8 CASE ASSY/UPPER
10241594 PANEL/DISPLAY RJC502533-001V03 1 1 11111 1 1 C
10250925 PANEL/DISPLAY RJC502533-002V03 1 1 1 C
8-2 10243936 PLATE/GUIDANCE RJC502542-001V03 1 1 1111111 1 1 1 C
8-3 10230486 KEY/TRG L RJC502526-001V01 1 1 1111111 1 1 1 X
8-4 10230487 KEY/TRG R RJC502532-001V01 1 1 1111111 1 1 1 X
8-5 10243938 W-TAPE/TRG KEY RJC502826-001V01 2 2 2222222 2 2 2 B
8-6 10230503 RUBBER/TRG RJC502527-001V01 2 2 2222222 2 2 2 B
8-7 10243944 W-TAPE/TRG RUBBER RJC502753-001V02 2 2 2222222 2 2 2 B
8-8 10232013 PWB/TRG RJC502429-001V01 2 2 2222222 2 2 2 X
8-9 10231721 WIRE ASSY/TRG RJC502581*001V01 2 2 2222222 2 2 2 C
8-10 10239189 HOLDER/TRG RJC502643-001V01 2 2 2222222 2 2 2 X
R
8
DescriptionsPart NameCode No.
Q'ty
1
2
N Item
8-1
1 DT-930M51E
2 DT-930M50E
3 DT-930M51NBE
4 DT-930M50NBE
5 DT-930M50G
6 DT-930M51E-CN
7 DT-930M50E-CN
8 DT-930M50E-2-CN
9 DT-930M51NBE-CN
10 DT-930M50NBE-CN
11 DT-940M51E-CN
12 DT-940M51NBE-CN
