― 65 ―
APPENDIX. HA-E60IO (PARTS LIST)
Item Code No. Part Name Description Q'ty R
1 10242985 CASE/UPPER RJC502703-001V01 1 X
2 10242987 PANEL/LED RJC500711-006V01 1 X
3 10242989 PDT GUARD RJC502731-001V01 1 X
4 10242991 BLIND/UPPER RJC502768-001V01 1 X
5 10102278 SCREW/BIND TAP S-BDB0-2X6NI 4 X
6 10242995 HOLDER/PDT RJC502712-001V01 1 X
7 10120352 FILTER/IR RJC501082-001V01 1 X
8 10102323 LENS/LED RJC500723-001V01 1 X
9 10102324 W-TAPE/LED RJC500726-001V01 1 X
10 10102329 BUTTON/DETECT RJC500720-001V01 1 C
11 10242993 PCB ASSY/PDT RJC502713E101 1 B
12 10242994 PCB ASSY/IRDA RJC502716E101 1 B
13 10102278 SCREW/BIND TAP S-BDB0-2X6NI 4 X
14 10242090 PCB ASSY/MAIN RJC502710E101 1 A
15 BLIND/JACK RJC502775-001 1 C
16 10102311 SCREW S-PADLMA-2X6NI 8 X
17 10102305 BLIND/DIP SW C445258-002V01 1 X
18 10102320 RUBBER/FOOT SJ-5306 4 X
19 10097195 SCREW/BIND TAP S-BDB0-3X8NI 2 X
20 10111017 SCREW S-PASWMA-3X6NI 2 X
21 10102311 SCREW S-PADLMA-2X6NI 2 X
