Casio DT-940 User Manual

― 23 ―
4. DIAGNOSTIC PROGRAM
Diagnostic program exists in 64 Kbyte and exclusive use area among FROM and mixable with OS and KCG.
As for Bluetooth, please refer to 4.8 Bluetooth diagnostic method.
The document is processed based on Version 2.98.
Be sure to update the rmware after replacing the Laser Module (MDL-1001) of DT-940 with a new one.
For more information about DT-940 laser test, refer to “4.10 DT-940 LASER SCANNER CHECK”.
4-1. UPDATING DT-940 FIRMWARE
4.1.1 NECESSARY FILES
In order to execute the rmware version up for LASER MODULE, all the below les have to be transferred
to DT-940 Flash ROM (B drive).
It is done by using LMWIN or “DUPLICATE HT” in the System menu.
These les are contained in the “Dt930\Dt940_Laser_Firm” folder.
No Program name Contents
1 ASTARH.HTS Rewriting tool boot-up le
2 FL56J06.txt Firmware
3 mdlver.txt Updating data le
4 PATCH001.LOD Patch le
5 PATCH002.LOD Patch le
6 WRITEFW.LOD F/W Update Tool
Note: After updating the rmware, format the “B” drive and delete the above programs.
4.1.2 OPERATING PROCEDURE
NO. Display Operation Remarks/Result
1
F/W Update Tool
MAIN: FL56J06
FILE:
FL56J06
Update: 1
Cancel: 3
Execute AP starting up from
System Menu and start up F/W
Update Tool.
Input [1] to start.
F/W Update Tool
MAIN: FL56J06
FILE:
FL56J06
Writing . . .
09%
Screen shown during update
2
F/W Update Tool
MAIN: FL56J06
Complete!
Hit any key
When "Complete!" appers, input
any key.
3
システムメニュー
1 : AP キドウ
2 : モードセット
3 : ヒヅケ / ジコク セット
4 : テンソウ
5 : バージョン
Firmware version up for LASER
MODULE completed.
