Casio DT-940 User Manual

― 62 ―
12
3456789101112
RDescriptionsPart NameCode No.
Q'ty
N Item
INNER CASE BLOCK
10251583 PCB ASSY/MAIN RJC503131*001V01HK 1 1 1 1 A
10251582 PCB ASSY/MAIN RJC503131*002V01HK 1 1 11 A
10265310 PCB ASSY/MAIN RJC503131*003V01HK 1 1 A
N 10321972 PCB ASSY/MAIN TK-RJC503131*004 1 1 1 1 A
10321973 PCB ASSY/MAIN TK-RJC503131*005 1 1 1 1 A
10321974 PCB ASSY/MAIN TK-RJC503131*006 1 1 A
N 10396640 PCB ASSY/MAIN TK-RJC503131*007 1 A
N 10396641 PCB ASSY/MAIN TK-RJC503131*008 1 A
21 10230500 HOLDER/KEY RJC502576-001V01 1 1 1111111 1 1 1 X
10284459 LASER ASSY VLM-3900A 1 1 111111 1 A
N 10390660 LASER ASSY VLM-3900B 1 A
10232025 FFC/LASER RJC502565-001V01 1 1 1111111 1 C
N 10390031 FFC/LASER RJC505620-001V01 1 1 C
N 47 10396468 CUSHION/CN-HEC RJC505735-001V01 1 1 X
N 48 10390311 BASE/LS RJC505603-001V01 1 1 X
24 10246976 HOLDER/LS-S RJC502654-001V02 1 111 X
25 10239277 SHADE PLATE/LS-S RJC502660-001V01 1 111 X
26 10246977 HOLDER/LS-B RJC502659-001V02 1 11 11 1 X
27 10241601 W-TAPE/MIRROR RJC502540-001V02 1 11 11 1 X
28 10239190 MIRROR RJC502673-001V01 1 11 11 1 X
29 10238767 SHADE PLATE/LS-B RJC502661-001V01 1 11 11 1 X
30 10243934 PCB ASSY/BZ RJC502578*001V01HK 111111111 1 1 1 C
31 10243921 PCB ASSY/SUB RJC502506E101V01HK 111111111 1 1 1 C
32 10232026 FFC/SUB RJC502566-001V01 1 1 1111111 1 1 1 C
33 10235356 CUSHION/CN RJC502684-001V01 1 1 1111111 1 1 1 X
49 10215467 TAPE/B RJC501976-001V01 222222222 2 2 2 C
34 10230205 SCREW RJC502612-001V01 3 3 3333333 3 X
35 63289130 SCREW/FLAT HEAD A44793-7 4 4 4444444 4 4 4 X
36 10017815 SCREW/FLAT TAPPING HA310076-3 4 4 4444444 4 4 4 X
Components for Item #20 PCB ASSY/MAIN
20-1 10241306 SPRING/BATTERY P1 RJC502568-001V02 1 1 1111111 1 1 1 B
20-2 10241307 SPRING/BATTERY P2 RJC502569-001V02 1 1 1111111 1 1 1 B
20-3 10245261 SPRING/BATTERY M1 RJC502570-001V02 1 1 1111111 1 1 1 B
20-4 10245689 SPRING/BATTERY M2 RJC502571-001V03 1 1 1111111 1 1 1 B
20-5 10232533 CONNECTOR/SPRING C342166-001V01 1 1 1111111 1 1 1 B
22
20
23
z

20
1 DT-930M51E
2 DT-930M50E
3 DT-930M51NBE
4 DT-930M50NBE
5 DT-930M50G
6 DT-930M51E-CN
7 DT-930M50E-CN
8 DT-930M50E-2-CN
9 DT-930M51NBE-CN
10 DT-930M50NBE-CN
11 DT-940M51E-CN
12 DT-940M51NBE-CN
