147
Appendix
The numbers in parentheses indicate the pages where each item is explained.
. Camera
.
Charger Unit
General Guide
1
Shutter button (page 16)
2
[ON/OFF] (Power)
(page 22)
3
Flash (page 26)
4
Front lamp
(pages 18, 63)
5
Lens
6
Microphone
(pages 45, 93)
7
Back lamp
(pages 16, 22, 26)
8
Zoom controller
(pages 16, 42, 76, 77)
9
[
0
] (movie) button
(page 45)
bk
USB/AV port
(pages 78, 97, 105, 114)
bl
Connector cover
bm
Strap hole (page 2)
bn
[SET] button (page 23)
bo
[BS] button (page 50)
bp
[MENU] button
(page 56)
bq
Control button
([8][2][4][6])
(page 23)
br
[r] (REC) button
(pages 16, 22)
bs
[p] (PLAY) button
(pages 19, 22)
bt
Monitor screen
(pages 131, 148)
5
6
3
4
21
bqbrbtbs bp bo bn
bm
bl
87 9bk
[ ]
[ ]
[ ]
[ ]
[
SET
]
Front Back
ck
Battery/memory card slots (pages 12, 14, 142, 144)
cl
Speaker
cm
Tripod hole
Use this hole when attaching to a tripod.
ckcmcl
Bottom
3
2
1
1
[CHARGE] Lamp
2
+- Contacts
3
AC jack
