Using the Camera with a Computer
4. Turn off the camera and then use the USB cable that comes with the
camera to connect it to your computer.
• The camera does not draw power over the USB cable. Check the battery level
before connecting and make sure it is not too low.
• Make sure that you insert the cable connector into the USB/AV port until you
feel it click securely into place. Failure to insert the connector fully can result in
poor communication or malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
• When connecting the USB cable to a USB port, make
sure you align the connector correctly with the port.
• Your computer may not be able to recognize the
camera if you connect via a USB hub. Always connect
directly to the computer’s USB port.
5. Turn on the camera.
6. Windows 7, Windows Vista users: Click “Start” and then “Computer”.
Windows XP users: Click “Start” and then “My Computer”.
7. Double-click “Removable Disk”.
• Your computer recognizes the memory card loaded in the camera (or built-in
memory if there is no card) as a removable disk.
8. Right-click the “DCIM” folder.
9. On the shortcut menu that appears, click “Copy”.
USB port
USB cable
Making sure that the 6 mark on the camera is
aligned with the 4 mark of the USB cable
connector, connect the cable to the camera.
[USB/AV] port
Large connector
Small connector
Terminal cover

Casio EXILIM EX-ZR100 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	12.75 MP
Image sensor size	1/2.3 \
Image formats supported	JPG
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3264 x 2448, 3648 x 2736, 4000 x 2248, 4000 x 3000
Digital zoom	4 x
Optical zoom	12.5 x
Combined zoom	199.3 x
Focal length range	4.24 - 53 mm
Number of aspheric elements	1
Lens structure (elements/groups)	9/8
Digital SLR	No
Power source type	AC, Battery
Aperture range (F-F)	3 - 7.9
Camera shutter speed	1- 1/2000 s
Focal length (35mm film equivalent)	24 - 300 mm
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (wide)	0.01 - 0.5 m
Auto Mode focusing range (wide)	0.05 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Camera shutter type	Electronic, Mechanical
Flash modes	Auto, Flash off, Red-eye reduction
Scene modes	Close-up (macro), Panorama, Portrait, Self-portrait
Photo effects	-
White balance	Auto, Daylight, Fluorescent, Manual, Shade, Tungsten
Camera playback	Movie, Single image
Image processor	EXILIM Engine HS
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Video resolutions	640 x 480, 1920 x 1080 pixels
Motion JPEG frame rate	3 fps
Video formats supported	H.264, MOV
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Internal memory	52.2 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution	960 x 480 pixels
Display resolution (numeric)	460800 pixels
USB version	2.0
Product color	White
Battery type	NP-130
Cables included	AC, AV, USB

Weight and Dimensions

Depth	28.6 mm
Width	104.8 mm
Height	59.1 mm
Weight	165 g
Weight (including battery)	205 g
