Casio FX-9750G Operation, Service Manual & Parts List

12. PARTS LIST
N Item Code No. Parts Name Specification Q R
ZX933-1 ASS'Y
LSI3 2012 3192 LSI TC55257DFL-7085V
1
B
N LSI2 2012 5531 LSI UPD23C4001EJGW-C67
1
B
Q2 2250 1281 Chip transistor 2SA1179M5, M6, M7-TB
1
C
IC2 2105 2737 CMOS-IC RH5RL50AA-T1
1
B
X1 2590 1967 Ceramic oscillator CSTC4.30MG-TC
1
C
ZX933-2 ASS'Y
1 6416 9441 Battery spring A-Z933 A441557A-1
1
X
2 6416 9450 Battery spring B-Z933 A441558-1
1
X
3 3501 6538 Mini jack HSJ1169-012010
1
C
Q1 2259 0959 Chip digital transistor DTC114YKT-146
1
C
LCD UNIT
N 4 3335 6530 LCD CD1093-TS
1
B
5 6416 9370 LCD holder Z933 A341010-1
1
C
6 5610 9050 Heat seal C-Z933 A340956-1
1
B
7 5610 9060 Heat seal S-Z933 A341018-1
1
B
LSI5 6417 3441 COF3015-F1 sub ass'y C340532A*2
1
B
LSI6 6416 3211 COF3016-F1 sub ass'y C340533A*1
1
B
PCB UNIT
8 6416 9280 Z933-2 ASS'Y A240572*1
1
B
N 9 6419 5190 Z933-1 ASS'Y A140379P*3 HK
1
B
N 10 6419 5200 LCD UNIT A240603C*3 HK
1
B
11 6408 0210 PC joiner L370 A413642-1
1
B
COMPONENTS
12 6416 9340 Key contact rubber Z933 A240567-1
1
C
13 6416 9350 Hard case Z933 A240568-1
1
C
14 6416 9500 Battery holder A441594-1
1
X
15 6416 9380 Display plate Z933 A341011-1
1
C
16 6390 0432 Cap V332 A310765B-1
1
C
17 6413 5080 Button E-L392 A313257-3
1
C
18 6413 5090 Button F-L392 A313257-4
1
C
19 6413 5000 Button B-L392 A340110-1
1
C
20 6413 6000 Button H-L392 A340256-1
1
C
N 21 6419 5130 Button A-Z934 A240072-4
1
C
N 22 6419 5140 Button B-Z934 A211316-9
1
C
N 23 6419 5150 Button C-Z934 A340111A-3
1
C
N 24 6419 5160 Button D-Z934 A340123-2
1
C
N 25 6419 5170 Button G-Z934 A313257-7
1
C
N 26 6419 9360 Upper case Z934AY A140634-1
1
X
N 27 6419 9380 Badge label Z934AY A442505-1
1
C
N 28 6419 9870 Battery cover Z934AY A240903-1
1
C
29 6408 0110 Battery spring B-L370 A410113-3
2
X
30 6408 0120 Battery spring L370 A412218-2
1
X
N 31 6419 9840 Rubber key Z934 A341594-1
1
C
32 6416 9400 Lock spring Z933 A341016-1
1
C
N 33 6419 9922 Lower case Z934AY A140374B-5
1
X
34 6417 3520 Spring H-Z933 A441675-1
1
C
Notes: N – New parts Essential
Q – Quantity used per unit Stock recommended
R – Rank Others
No stock recommended
R – A :
B :
C :
X :
R – A :
B :
C :
X :
— 28 —
