24
2.4 Status Indications With LEDs
This chapter is not applicable to the HA-C60IO Basic Cradle.
Various operational statuses on the HA-C61IO can be displayed using the LEDs. The following table describes
LED indication modes and their meanings.
Table 2.5
Item LED mode Description Remark
LED
Off : Power off.
Green : Power is ON and the terminal is correctly
mounted on the Cradle.
Power status indicator
(“POWER”)
Red : Power is ON but the terminal is not correctly
mounted on the Cradle.
2-color LED
Off : No communication being performed.
Green (Flashing) : Communication is in progress.
Comm. status indicator
(“DATA”)
Red (Flashing) : Problem in the connection between two Bridge
Satellite Cradles.
2-color LED
Off : The system is not operating.
Line status indicator
(“LINE”)
Green (Flashing) : The system is correctly operating.
To Next Page
