4.3 Physical Durability
4.3.1 IT-10
Table 4.10
Item Specification Condition
Resistance to drop impact (height)
In bare condition 100 cm Onto concrete, one time on each of the 6 sides and 4 corners.
(with the CF being removed)
In individual carton box 70 cm or less
In master carton box 50 cm or less
Onto concrete, one time on each of the 6 sides, 1 corner, 3
edges.
Resistance to vibration 1.5 G or less 10 to 55 Hz
In X,Y, and Z directions
Reciprocally for 30 minutes
While the power is kept on (with the screen being turned
on).
4.3.2 HA-C60IO/HA-C61IO
Table 4.11
Item Specification Condition
Resistance to vibration
(in bare condition)
1.5 G or less 10 to 55 Hz
In X,Y, and Z directions
Reciprocally for 30 minutes
Resistance to vibration
(in package)
1.5 G or less 10 to 55 Hz
In X,Y, and Z directions
Reciprocally for 30 minutes
Resistance to impact
In bare condition 70 cm One time for 6 faces onto concrete surface
In individual carton box 70 cm or less
In master carton box 50 cm or less
One time for 6 faces, 1 corner and 3 edges
4.3.3 HA-C32DCHG
Table 4.12
Item Specification Condition
Resistance to vibration
(in bare condition)
1.5 G or less 10 to 55 Hz
In X,Y, and Z directions
Reciprocally for 30 minutes
Resistance to vibration
(in package)
1.5 G or less 10 to 55 Hz
In X,Y, and Z directions
Reciprocally for 30 minutes
Resistance to impact
In bare condition 70 cm 6 faces, 1 corner and 3 edges
In individual carton box 70 cm or less
In master carton box 60 cm or less
6 faces, 1 corner and 3 edges
