E-64
Using PC Cards
Removing a PC Card
Press the eject button on the left side of PC
card slot with the stylus as shown by the
arrow, and pull out the PC card while
holding onto the end of the PC card
removal tape.
Inserting a PC Card (When Using the Paper Holder)
Check the names of the parts of the Paper Holder before beginning work.
1. Check that the power is off. If the power is on, always make sure to turn it off by
pressing the power key.
2. Spread apart both ends of Part A of the
Paper Holder ( ) and remove it from
the Handheld Printer Terminal ( ), and
then remove Part C and Part D ( ).
• Remove Part C and Part D using an
ordinary screwdriver as shown in the
illustration.
Part B
Part D
Part C
Part A
Screws (4)
PC card cushion
C
D
A
1
1
2
3
3
1
2
3
To Next Page
