E-66
7. While spreading apart both ends of Part A
( ), remove Part A from the Handheld
Printer Terminal by lifting up Part A until
the projections reach the upper edges of
the grooves of Part B ( ), and then press
on Part C and Part D from the left and
right sides ( ). Next, push on both ends
of Part A to fasten to the Handheld
Printer Terminal.
When Removing the PC card
Press the eject button on the left side of the
PC card slot with the stylus, and then pull
out the PC card while grabbing onto the
end of the PC card removal tape. (The
illustration shows the Handheld Printer
Terminal turned over.)
1
1
2
3
3
1
2
3
Using PC Cards
