LK-127
– 9 –
A-3. Turn over the panel unit.
A-4. Unsolder two battery lead wires and two ribbon cables.
Lead wire (Red)
Lead wire (Black)
Ribbon cable
(
KYA2 PCB
)
Ribbon cable
(LDA2 PCB)
A-5. Remove the panel unit.
PCB UNIT/MAINPCB UNIT/POWER & AMP
