Reference
EN-71
English
• Specifications and designs are subject to change without notice.
Inputs/Outputs • PHONES jack: Stereo standard jack × 1
• PEDAL1 jack: Standard jack × 1
• PEDAL2, EXPRESSION jack: Standard jack × 1
• Power: 24V DC
• MIDI OUT/THRU, IN terminals
• LINE IN R, L/MONO jacks: Standard jacks × 2
Input impedance: 9.0K
Ω
Input voltage: 200mV
• LINE OUT R, L/MONO jacks: Standard jacks × 2
Output impedance: 2.3K
Ω
Output voltage: 1.8V (RMS) MAX
• Audio In: Stereo mini jack
Input impedance: 9.0K
Ω
Input voltage: 200mV
• USB port: Type B
• USB flash drive port: Type A
• Microphone input terminal: Standard jack (Connect a dynamic microphone.)
Input impedance: 3.0K
Ω
Input sensitivity: 10mV
Speakers
φ
12cm × 2 +
φ
5cm × 2 (Output 20W + 20W)
Power Requirements AC Adaptor: AD-E24250LW
• Auto Power Off: Approximately 4 hours after last operation. Auto Power Off can be disabled.
Power Consumption 24V = 20W
Dimensions 95.0 (W) × 40.0 (D) × 15.1 (H) cm (37
7
/
16
× 15
3
/
4
× 5
15
/
16
inch)
Weight approximately 7.6kg (16.8 lbs)
MZX300_X500-ES-1A.indd 73 2015/10/07 15:46:53
