— 6 —
3) RAM write and read check
The machine writes data into RAM and read out the data to compare with written data.
When this check is finished correctly, the machine goes to check No. 4).
However, if an error is occurred, the machine sounds an error tone, prints the error receipt,
and stops Hard check program.
Error receipt sample " — — — — — — — 2"
4) Drawer open check
5) Receipt issue
6) Test character print
1234567890 CATL
7) Test display
123456.78
Note : Decimal point on the display depends on the PAD condition.
4-4-2. Print test
Operation : 2+ST
Prints the following character continuously.
To stop this test, press any key or turn the mode switch to "OFF" position.
Printing speed
45 times / Min.
Print character
Note: In case press " 1 2 + ST ", the following test is executed.
Printing speed: 25 times / Min.
Drawer open : 5 times / Min.
Stamp print: 5 times / Min.
• 88 • 88
To Next Page
