SE-S100 / PCR-T285 / PCR-T295
– 2 –
2. IPL (INITIAL PROGRAM LOADER)
Important:
Main PCB (E261-1 PCB) supplied as spare parts have been pre-installed application and diagnostic
software at the timing of product.
So check the version number of main PCB you replaced and install an appropriate application software,
if necessary.
2-1. Preparation
Prepare the SD card which contains the APLI module (IPL fi le) in the root directory.
2-2. Procedure
(1) Unplug the power cord.
(2) Turn the Mode switch to [PGM], then while pressing
f
, plug the power cord.
(3) When a pip sound is heard and “BT INT” is displayed, release
f
.
(4) Insert the SD card into the SD card slot.
(5)
4
4
4
4
9
9
9
9
o
(6)
3
0
o
IPL runs.
YY XX
YY XX
YY
: Depends on the application.
XX
: Counts up from 1 to YY, and stops at YY.
(7) When IPL is completed:
Without LOCALE information Since the diagnostic program automatically runs, carry out the
LOCALE setting.
Refer to the fl ow in “Initial LOCALE judgment/settings” (P3).
With LOCALE information Proceeds to the language setting.
Refer to the setting fl ows by destination (P4 to 7).
To Next Page
