Casio Privia PX-870 User Manual

Getting Ready
EN-51
3-2. If you plan to locate the piano and stand
against a wall, loosen the two screws (one on
the outside of each side panel) that secure
the brackets. You do not need to remove the
screws in this case.
• In this case, you do not need to remove the screws.
Just loosen them.
4. Insert angle brackets  into the gap between
the anti-tipping bracket and the side panel.
5. From the outside of side panels

and

,
temporarily tighten the screws you loosened
in step 3, above.
6. Place the two ends of the pedal unit  onto
the
 brackets and secure them with 
screws. Finish with
 screw caps.
7. While pressing the pedal unit down towards
the floor, securely tighten the screws you
partially tightened in step 5.
I
E
G
J
G
J

Casio Privia PX-870 Specifications

General

Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Touch Sensitivity	3 sensitivity levels, Off
Polyphony	256 notes
Tones	19 built-in tones
Speakers	12cm x 2, 4cm x 2
Amplifiers	20W + 20W
USB	Type B
Power Consumption	18W
Sound Source	AiR Sound Source
Acoustic Simulator	Damper Resonance, String Resonance
Effects	Reverb (4 types), Chorus (4 types), Brilliance, DSP
Lesson Function	Yes
Recorder	2 tracks, 5, 000 notes total
Metronome	0 to 9 beats; tempo range: 20 to 255
Transpose	25 steps (-12 semitones to +12 semitones)
Tuning	A4 = 415.5Hz to 440.0Hz to 465.9Hz
Pedals	3 pedals (damper, soft, sostenuto)
Connectors	2 x Headphones
Line Out	Yes
Power Source	AC adaptor: AD-E24250LW
Included Accessories	AC adaptor, Music Stand
Headphones	Stereo mini jack (3.5mm) x 2
