– 24 –

Be sure to install each hammer at its designated location. If a hammer does not move smoothly, check

if it is installed at the correct location.

Follow the same procedures shown below to install a hammer for both black and white keys.

1. Use the tweezers to set a hammer at its correct location.

2. Press the chassis with the tip of tweezers.

3. Using the chassis-tweezers contact as a fulcrum point, press down the metal part of the hammer in

the direction of the red arrow in the illustration below, and then install the hammer.

NOTE: When installing, do not damage the felt.

Be careful not to damage the felt.

Press down against the metal part.

Tweezers

Fulcrum point

Locked at this point
