PX-150
– 33 –
<Installing the Hammers>
• Follow the steps below to install the hammers for white and black keys.
NOTE: Thehammersmustbearrangedinaspecicorder.Installthemaccordingtothe
correct order.
NOTE:
If a hammer does not move smoothly, check to see if it is installed at the correct
location.
(1) Use the tweezers to set a hammer at its correct location.
(2) Press the chassis with the tip of tweezers.
(3) Using the chassis-tweezers contact as a fulcrum point, press down the metal part of the
hammer in the direction of the red arrow shown below, and then install the hammer
.
NOTE:
Be careful not to damage the felt.
Press down against the metal part.
Tweezers
Fulcrum point
Locked at this point
Be careful not to damage the felt.
