PX-150
– 52 –
1: PX-150_BLACK_DI
2: PX-150_BLACK_EU
3: PX-150_BLACK_UK
4: PX-150_BLACK_US
5: PX-150_WHITE_DI
6: PX-150_WHITE_EU
7: PX-150_WHITE_UK
8: PX-150_WHITE_US
12345678
Specification R RemarksN Item Code No. Parts Name
Q'ty
CNA PCB & HPA PCB
N 3 10433485 PCB UNIT/CNA TK-RJM512320*001 11111111CCNA1/CNA2
N VR601 10399354 VARIABLE RESISTOR F-09KH1-CASIO-2 11111111BMain volume
D601,D603-D609 10336974 LED 26-21/R1 88888888X
D602 10336975 LED 26-21/Y1 11111111X
SW601-SW608 10337110 SWITCH TP-1138A-10-100GF 88888888X
D610-D612 23901820 DIODE 1SS355TE-17 33333333X
N 4 10433486 PCB UNIT/HPA1 TK-RJM512319*001 11111111CHPA1
J701,J702 10132088 JACK/PHONE JY-6360*01-070 22222222B
L701,L702 10231919 COIL RB53-856396NP 22222222X
KEYBOARD PCB
N 5 10437588 PCB UNIT/KY and RUBBER CONTACT TK-RJM512336*002 11111111CKYA1/KYB1/KYC1
D1-D46 10301580 DIODE LM1MA142WAT1G 46 46 46 46 46 46 46 46 X
Q101-Q364 69300298 TRANSISTOR 2SC4081T106R 264 264 264 264 264 264 264 264 X
CONSOLE UNIT
N 6 10427188 CASE/PANEL RJM512078-001V01 1111 X
6 10431951 CASE/PANEL RJM512078-002V01 1111X
7 10337054 LED COVER RJM509410-001V01 3333 X
7 10448030 LED COVER RJM509410-003V01 3333X
N 8 10428304 LED COVER RJM512166-001V01 2222 X
N8 10448004 LED COVER RJM512166-003V01 2222X
N 9 10428263 LED SPACER/A RJM512126-001V01 22222222X
10 10428264 LED SPACER/B RJM512127-001V01 11111111X
11 10342127 TACT BUTTON/A RJM509408-002V01 1111 X
N 11 10431934 TACT BUTTON/A RJM509408-005V01 1111X
12 10431933 TACT BUTTON/A RJM509408-004V01 1111 X
N 12 10431935 TACT BUTTON/A RJM509408-006V01 1111X
13 10337029 TACT BUTTON/B RJM509396-001V01 1111 X
N 13 10431931 TACT BUTTON/B RJM509396-005V01 1111X
14 10337030 TACT BUTTON/B RJM509396-002V01 2222 X
N 14 10431932 TACT BUTTON/B RJM509396-006V01 2222X
N 15 10428362 KNOB/for ROTARY RJM512136-001V01 1111 C
N 15 10431952 KNOB/for ROTARY RJM512136-002V01 1111C
