Casio PX-330BK User Manual

1: PX-330_DI
2: PX-330_EU
3: PX-330_UK
4: PX-330_US
5: PX-330_WHITE_DI
6: PX-330_WHITE_EU
7: PX-330_WHITE_UK
8: PX-330_WHITE_US
– 54 –
12345678
MAIN PCB (MDA1)
N 1 10346441 PCB ASSY/MAIN TK-RJM509703*001 11111111 B MDA1
2 69261580 SPONGE-35-150 M440499-001 11111111 X
CN9 10257512 CONNECTOR UBR23-4K5G00 11111111 C USB
N IC11 10226394 IC TC74VHC08FT(EL.K) 11111111 X
N IC10 10206819 IC TC7SZ32FU(TE85L.F) 11111111 X
IC13 10256338 IC CS4351-CZZR 11111111 X
IC1 10241413 IC R1151N001C-TR-F 11111111 X
IC8 10123002 IC TC74VHC174FT(EL) 11111111 X
IC9 10258396 IC TC74VHC541FT(EL.K) 11111111 X
IC4 10197554 IC TC7SZ126FU(TE85L.F 11111111 X
IC5 10255468 LSI MB91F036PFF-GE1 11111111 C
IC14 10333782 LSI UPD65943GK-F659EUA 11111111 C
N IC6 10335496 MEMORY S29GL512P10TFCR20D 11111111 C
IC3 10197390 MEMORY LP62S2048AX70LLTFQ 11111111 C
IC2 10333111 MEMORY MD56V82160-6TAZ03B 11111111 C
D31 10276977 DIODE L1SS400T1G 11111111 X
L39 10193074 COIL DLW21HN181SQ2L 11111111 X
Q8,Q9 69409403 TRANSISTOR 2SA1576AT106R 22222222 X
Q7 22592764 TRANSISTOR 2SB1188T100Q 11111111 X
Q10 69300298 TRANSISTOR 2SC4081T106R 11111111 X
X1,X31 10334293 RESONATOR 9C12000163 22222222 X
SUB PCB (PSA1)
N 3 10346442 PCB ASSY/PSA1 TK-RJM509704*001 11111111 C PSA1
4 10169597 BRACKET/JACK RJM504221-001V01 11111111 X
5 69263990 SPONGE-35-190 M440556-001 22222222 X
N 6 10048977 FABRIC TAPE M440684-002
11111111 X
J203,J204 10206815 CONNECTOR JY-6314*01-030 22222222 C JACK for PEDAL
J202 10334294 CONNECTOR KM02022ABMP 11111111 A DC JACK
CN216 10207671 CONNECTOR HDC-052SP-02 11111111 X MIDI IN/OUT
IC203 10201503 IC PQ1CG21H2FZH 11111111 X
IC202 10306512 IC TDA7297 11111111 C
IC201 10306415 IC BH3547F-E2 11111111 X
IC204,IC205 10211950 IC NJM2068M-D(TE1) 22222222 X
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name
