Casio PX-330BK User Manual

1: PX-330_DI
2: PX-330_EU
3: PX-330_UK
4: PX-330_US
5: PX-330_WHITE_DI
6: PX-330_WHITE_EU
7: PX-330_WHITE_UK
8: PX-330_WHITE_US
– 55 –
1: PX-330_DI
2: PX-330_EU
3: PX-330_UK
4: PX-330_US
12345678
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name
Q201-Q210,
Q213
69300298 TRANSISTOR 2SC4081T106R 11 11 11 11 11 11 11 11 X
Q211,Q212 10305853 TRANSISTOR KTD1304-RTK/P 22222222 X
L208 10231919 COIL RB53-856396NP 11111111 X
L202-L204,
L206,L207
10231920 COIL RB53-856397NP 55555555 X
L205 10232457 COIL RII7-860400NP 11111111 X
N D209 10314562 PHOTO COUPLER QCPL-M614-500E 11111111 X
D205,D208 10276977 DIODE L1SS400T1G 22222222 X
D204 10334295 DIODE LUDZS12BT1G 11111111 X
D206,D207 10308381 DIODE LUDZS7.5BT1G 22222222 X
D202 10334296 DIODE LUDZS8.2BT1G 11111111 X
D203 10210387 DIODE RSX101VA-30TR 11111111 X
D201 10294394 DIODE SK34A 11111111 X
JACK PCB (JKA1)
N 7 10346443 PCB ASSY/JKA1 TK-RJM509715*001 11111111 C JKA1
J503 10206815 CONNECTOR JY-6314*01-030 11111111 B LINE OUT (L)
J501,J502,
J504
10206816 CONNECTOR JY-6314*01-130 33333333 B
LINE IN,
LINE OUT (R)
L501-L504 10231920 COIL RB53-856397NP 44444444 X
CONSOLE PCB (CNA1)
N 8 10346447 PCB ASSY/CNA3 TK-RJM509711*001 11111111 X CNA3
VR601 10123103 VARIABLE RESISTOR RK09K12C0D1B 11111111 B Main volume
N 9 10346445 PCB ASSY/CNA1 TK-RJM509707*001 11111111 X CNA1
SW601-SW615 10337110 SWITCH TP-1138A-10-100GF 15 15 15 15 15 15 15 15 X
D601-D604,
D606-D614
10336974 LED 26-21/R1 13 13 13 13 13 13 13 13 X
D605 10336975 LED 26-21/Y1 11111111 X
N 10 10346448 BACK LIGHT ASSY TK-RJM509840*001 11111111 X
N D2 10336988 LED HSW1142LT-13-TR 11111111 X
N LSI1 10291684 LSI D78F1153GK-GAK-AX 11111111 X
Q3,Q27 69409403 TRANSISTOR 2SA1576AT106R 22222222 X
