Casio PX-330BK User Manual

1: PX-330_DI
2: PX-330_EU
3: PX-330_UK
4: PX-330_US
5: PX-330_WHITE_DI
6: PX-330_WHITE_EU
7: PX-330_WHITE_UK
8: PX-330_WHITE_US
– 56 –
1: PX-330_DI
2: PX-330_EU
3: PX-330_UK
4: PX-330_US
12345678
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name
Q1,Q2,
Q25,Q26
10178530 TRANSISTOR 2SA1873-GR(TE85L.F 44444444 X
Q9-Q11 10209027 TRANSISTOR KTC4076-Y-RTK/P 33333333 X
D3 10308381 DIODE LUDZS7.5BT1G 11111111 X
N 11 10346446 PCB ASSY/CNA2 TK-RJM509709*001 11111111 X CNA2
SW616-SW632 10337110 SWITCH TP-1138A-10-100GF 17 17 17 17 17 17 17 17 X
D615-D629 10336974 LED 26-21/R1 15 15 15 15 15 15 15 15 X
D650 10276977 DIODE L1SS400T1G 11111111 X
12 10310734 PCB ASSY/SDA1 TK-RJM508899*001 11111111 X SDA1
13 10208428 FERRITE CORE CTRC-0813(B) 11111111 X
N 14 10337091 SPACER RJM509862-001V01 44444444 X for SDA1
N 15 69265810 SPONGE-35-60 M440593-001 11111111 X
PANEL UNIT
N 16 10346444 PANEL ASSY TK-RJM509773*001 1111 X
N 16 10409766 PANEL ASSY TK-RJM509773*002 1111 X
N 17 10337025 PANEL RJM509390-001V01 1111 X
N 17 10404274 PANEL RJM509390-004V01 1111 X
18 10341073 COVER ASSY/SPEAKER TK-RJM509617*001 2222 X
N 18 10342736 COVER ASSY/SPEAKER RJM509617*002V02 2222 X
19 10175757 PACKING/10X386 RJM504743-001V01 22222222 X
20 10262597 DOUBLE FACED TAPE/3X50 RJM507716-001V01 22222222 X
21 10145912 FABRIC TAPE/5X16 RJM503705-001V01 66666666 X
22 10336976 SPEAKER C0612RJ01 22222222 X
23 10342353 HARNESS EF-EH2P031M900 11111111 X for Left speaker
24 69263990 SPONGE-35-190 M440556-001 11111111 X
25 10309718 HARNESS EH-2P-59-M334 11111111 X for Right speaker
26 10336990 SPONGE M410119-001 22222222 X
27 10305155 SPEAKER C05JT02 22222222 X Tweeter
N 28 10265690 HARNESS PH-2P-50-M332 11111111 X for Left tweeter
N 29
10336991 SPONGE-22-390 M441156-001 11111111 X
N 30 10342355 HARNESS EF-PH2P076M901 11111111 X for Right tweeter
31 69261580 SPONGE-35-150 M440499-001 11111111 X
N 32 10337058 BRACKET/TWEETER RJM509414-001V01 22222222 X for Tweeter
N 33 10346449 COVER ASSY/LEFT TK-RJM509775*001 1111 X
N 33 10404275 COVER ASSY/LEFT RJM509775*002V01 1111 X
