Data Format
Bulk dumping SMF data transfers the data with a 128-byte header appended as shown below. The header data starts with
an 8-byte file name, which is displayed by this Model after receipt.
39 Flash Memory Image Parameter Set
This Parameter Set is used for dumping flash memory contents. One Parameter Set corresponds to an image block
of 2 Mbytes of flash memory. The 4 Mbytes of flash memory of this Model is made up of two blocks, so two
Parameter Sets are used.
System Exclusive Format
Header 128Bytes Name 8Bytes
Reserved 120Bytes
SMF Data
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,02
04 dev 00 to 1F, or 7F
05 act 04(HDS), 05(HDR), 07(Control)
06 cat Flash Memory Image = 11
07 prm 00
08 ilen/dlen See "IV This Model’s System Exclusive Message".
09 ps Indicates the Flash Image Block Number being transferred.
For details, see "40 About Parameter Set (PS) numbers".
10 index See "IV This Model’s System Exclusive Message".
11 data See "IV This Model’s System Exclusive Message".
12 sum See "IV This Model’s System Exclusive Message".
13 EOX F7
