Note1: For information about the relationship between setting values and send/receive values, see the “33.1 Off/On Setting
Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Transmit Sent when a mixer part on/off setting is changed.
Receive Receipt changes the mixer part on/off setting.
7.25.2 Stage Setup Number Select
Message Format: BnH 62H 00H
BnH 63H 24H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: Value (00H - 63H)
ll:
Transmit Sent when the stage setup number is changed while Stage Set.Chg is NRPN by Instrument
settings.
Receive Receipt while Stage Set.Chg is NRPN by Instrument settings changes the stage setup number.
7.25.3 DSP Bypass
Message Format: BnH 62H 01H
BnH 63H 22H
BnH 06H mmH
BnH 26H llH
n: MIDI Channel Number
mm: Value (Note1)
ll: (Transmit:00h, Receive:Ignored)
Transmit Sent when the DSP Bypass on/off setting is changed.
Receive Receipt changes the DSP Bypass on/off setting.
Note1: For information about the relationship between setting values and send/receive values, see the “33.2 DSP Bypass
Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
7.25.4 DSP Parameter
DSP parameters can be changed by NRPN. The relationship between each parameter and NRPN numbers
is shown below.
17
