Parameter MSB LSB Notes
DSP Parameter[1] 23H 00H
DSP Parameter[2] 23H 01H
: : :
DSP Parameter[16] 23H 0FH
For details about each DSP parameter, see ”VII DSP Parameter List”.
7.25.5 Tone
Tone parameters can be changed by NRPN. The relationship between each parameter and NRPN num-
bers is shown below.
Tone Common Edit
Parameter MSB LSB Notes
Volume 3FH 00H
Reverb Send 3FH 01H
Chorus Send 3FH 02H
Delay Send 3FH 03H
Dynamic Panning 3FH 10H Note1
Note1: For information about the relationship between setting values and send/receive values, see “33.1 Off/On Setting Value
Table” in “VIII Setting Values and Send/Receive Values” of this document.
Non-drum Tome Edit In the case of non-hex layer tones, setting values are applied in relation to
reference values possessed by tones. In the case of hex layer tones, setting values are basically applied
as absolute values. However, drum tones are not applied when they are received.
Parameter MSB LSB Notes
LFO Pitch Rate 01H 08H
LFO Pitch Depth 01H 09H Note1
LFO Pitch Delay 01H 0AH
Filter Cutoff 01H 20H Note2
Filter Resonance 01H 21H Note2
Amp&Filter Attack Time 01H 63H Note2
Amp&Filter Decay Time 01H 64H Note2,Note3
Amp&Filter Release Time 01H 66H Note2,Note4
Note1: For a hex layer tone, for information about the relationship between setting values and send/receive values, see “33.25
–128 - 0 - +127 Setting Value Table” in “VIII Setting Values and Send/Receive Values” of this document.
Note2: For a hex layer tone, the values of all layers are changed.
Note3: For a hex layer tone, the values of Decay 1, 2, and 3 Time are changed.
Note4: For a hex layer tone, the values of Release 1 and 2 Time are changed.
Hex Layer Edit
Parameter MSB LSB Notes
Layer On/Off 5XH 00H Note1
Octave Shift 5XH 01H Note2
Pitch LFO Depth 5XH 02H
Filter LFO Depth 5XH 03H
Amp Volume 5XH 04H
Amp Pan 5XH 05H Note3
Amp LFO Depth 5XH 06H
DSP On/Off 5XH 07H Note1
18
