– 84 –

10-7. Attaching the shield sheet to the FFC/FPC cable

Wrap the shield sheet to the FFC cable as shown in the gure.

Attachtheshieldsheettotherein-

forcingplate

AppropriateFFC;

 • PWFFC

 • KEYFFC

 • 14pinI/FFFC

Attachtheshieldsheettotherein-

forcingplate

AppropriateFPC;

 • CMOSImagerFPC

Attach the shield sheet on both sides (front and back) of the Printer FPC.

Shieldsheet

Afxingstandard:

SidesurfaceofFPC

Afxingstandard:

HoleofFPC

(Rearview)

(Frontview)
