— 94 —
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Prices and Specications are subject to change without prior notice.
1 IT-3100M53E 3 IT-3100M54E 5 IT-3100M55E 7 IT-3100M55U 9 IT-3100M56E2
2 IT-3100M53E2 4 IT-3100M54E2 6 IT-3100M55E2 8 IT-3100M56E 10 IT-3100M56U
INNER CASE ASSY
10 10157881 SPRING/BATTERY RJC501201-001V02 1 1
11 10244818 SCREW/FLAT HEAD RJC502613-015V01 6666666666X
12 10306526 CASE/INNER RJC504037-001V01 1 1
13 10313396 SPRING RJC504109-001V01 3 3
14 10306525 RUBBER/LCD RJC504035-001V01 1 1
15 10308804 LCD MODULE COM35H3827XLC 1 1
16 10315782 TOUCH PANEL ASSY RJC501220*002V01 1 1
17 10157884 SHIELD/TOUCH PANEL RJC501219-001V02 1 1
18 10157890 PLATE/PRINTER RJC501288-001V02 1 1
19 10161404 PRINTER FTP-638MCL518 1 1
20 10190459 SHEET/SHIELD RJC501759-001V02 2 2
21 10160641 SCREW/BIND S-BDMA-2X3NIME 2 2
22 10232808 SCREW/FLAT HEAD RJC502613-011V01 3 3
23 10157905 PAPER GUIDE RJC501563-001V01 1 1
24 10160645 SCREW S-FLMA-2X3BME 2 2
25 10147504 PLATE/GROUND RJC501217-001V01 2 2
26 10316199 PCB ASSY/MAIN RJC504104*001V01 1
1 1 1 1 1A
26 10343247 PCB ASSY/MAIN RJC504104*003 TK 1 1 A
N 26 10384091 PCB ASSY/MAIN RJC505103*001 TK (1) 1 (1) 1 A
N 26 10384092 PCB ASSY/MAIN RJC505103*002 TK (1) 1 (1) (1) 1 (1) A
27 10306527 HOLDER/CAPACITOR RJC504036-001V01 1 1
28 10158657 PCB ASSY/14PINI/F RJC501235E101V01TK 1 1
29 10158652 BACKUP BATTERY ASSY RJC501344*001V01TK 1 1
30 10158653 CAPACITOR ASSY RJC501261*001V01TK 1 1
31 10314435 HOLDER/8PINI/F RJC501215-002V01 1 1 1 1 X
32 10158659 8PIN I/F ASSY RJC501463E101V01TK 1 1 1 1 C
33 10313395 TAPE/AT RJC504110-001V01 1 1
34 10157911 ANTENNA/BLUETOOTH CF-MF/G/M-BT-780 1 1
35 10169682 BUTTON/DETECT RJC501212-001V02 1 1
36 10314430 STOPPER/CARD RJC504119-001V01 1 1
37 10314431 TAPE/CARD STOPPER RJC504123-001V01 1 1
Item#28 PCB ASSY/14PINI/F
28-1 10147696 FFC CABLE/14PIN I/F RJC501233-001V01 1 1
28-2 10165057 SHEET/SHIELD RJC501616-001V01 1 1
Descriptions R
QUANTITY
N Item Part No. Part Name
To Next Page
