— 95 —
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Prices and Specications are subject to change without prior notice.
1 IT-3100M53E 3 IT-3100M54E 5 IT-3100M55E 7 IT-3100M55U 9 IT-3100M56E2
2 IT-3100M53E2 4 IT-3100M54E2 6 IT-3100M55E2 8 IT-3100M56E 10 IT-3100M56U
LOWER CASEASSY
10315787 RJC501568*005 1 1
10316205 RJC501568*006V01 1 11
10316206 RJC501568*007V01 1 1
10316207 RJC501568*008V01 1 1 1
39 10313393 SPACER/ASK RJC501491-002V01 1 1
40 10313224 POWER SUPPLY TERMINAL ASS
RJC501277*002V01 1 1
41 10307554 COVER/14PIN I/F RJC501275-003V01 1 1
42 10313394 PACKING/14PIN I/F RJC501301-002V01 1 1
43 10147459 SCREW RJC501456-001V01 4 4
44 10147556 FPC/TRIGGER RJC501256-001V01 1 1
45 10313231 COVER/TRIGGER RJC501276-002V01 2 2
46 10169877 SHIELD SHEET RJC501583-001V02 1 1
47 10246158 SCREW RJC502609-003V01 6 6
Item#38 CASE ASSY/LOWER
38-1 10147560 BUTTON/RESET RJC501447-001V01 1 1
38-2 10105235 COVER/RESET RJC500631-001V01 1 1
38-3 10306548 COVER/SD CARD RJC502551-002V01 1 1
38-4 10313226 COVER/8PIN I/F RJC504058-001V01 1 1 1 1 X
38-5 10313227 COVER/DC JACK RJC504057-001V01 1 1
38-6 10157914 TAPE/IR RJC501490-001V01 1 1
38-7 10147565 FILTER/IR RJC501465-001V01 1 1
38-8 10147570 RUBBER/FOOT SJ-5702 2 2
38-9 10306551 COVER/STRAP RJC501298-002V01 1 1 1 1 1 X
38-10 65140332 SHAFT/STRAP(A) C441990-001 2 2 2 2 2 X
38-11 10026079 SHAFT/STRAP(B) C444214-1 1 1 1 1 1 X
38-12 10246158 SCREW RJC502609-003V01 2 2
38-13 10306547 CASE/MCR UPPER RJC501312-002V03 11111 X
38-14 10147558 PACKING/STRAP RJC501299-001V01 11111 X
38-15 10313228 TAPE/TRIGGER RJC504108-001V01 2 2
38-16 10306546 BUTTON/TRIGGER RJC504042*001V01 2 2
ROLL PAPER HOLDER ASSY
48 10315784 ROLL PAPER HOLDER ASSY RJC501273*003V01 1 1
Item#48 ROLL PAPER HOLDER
48-1 10192604 PCB ASSY/PR RJC501756E101V01TK 1 1
48-2 10307019 HOLDER/PLATEN RJC501289-002V03 1 1
48-3 10187661 SHADING TAPE RJC501748-001V01 1 1
48-4 10160638 SHEET/PAPER GUIDE RJC501573-001V01 1 1
48-5 10246156 SCREW RJC502686-003V01 8888888888X
48-6 10307021 COVER/WATER SPLASH RJC501296-002V02 1 1
48-7 10160421 CUSHION/WATER SPLASH RJC501293-001V02 1 1
48-8 10147598 SCREW C444126-002V01 2 2
48-9 10307024 PAPER STOPPER RJC501635-002V02 1 1
Part Name Descriptions
QUANTITY
N Item Part No.
38 CASE ASSY/LOWER C
Part Name Descriptions R
QUANTITY
N Item Part No.
R
To Next Page
