— 96 —
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q: Quantity used per unit
R: Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
3. Prices and Specications are subject to change without prior notice.
1 IT-3100M53E 3 IT-3100M54E 5 IT-3100M55E 7 IT-3100M55U 9 IT-3100M56E2
2 IT-3100M53E2 4 IT-3100M54E2 6 IT-3100M55E2 8 IT-3100M56E 10 IT-3100M56U
OTHERS
49 10307567 TAPE/PL/L RJC503585-002V02 1 1
50 10307568 TAPE/PL/R RJC503586-002V02 1 1
PLATEN NA02266-V06201
(This is the same part bundled with Item #19 PRINTER.)
52 10315783 BATTERY COVER ASSY RJC501265*002V01 1 1
53 10147460 PIN/PARALLELE P-PP-2X20SUS 1 1
54 10147458 SCREW S-PAMA-2X8NI 2 2
55 10246155 SCREW/FLAT HEAD RJC502613-021V01 2 2
56 10244818 SCREW/FLAT HEAD RJC502613-015V01 3333111111X
57 10147455 SCREW/SPECIAL RJC500914-002V01 8 8 12 12 12 12 12 8 8 8 C
58 10147456 SCREW S-PAMA-2X6B 2 2
MCR BLOCK
59 10163679 PACKING/MCR RJC501316-001V01 11111 X
60 10180625 HEAD UNIT/MCR MCP-1381-1 11111 C
61 10180626 PCB ASSY/MCR RCK-3468-2 11111 C
62 10163685 FPC/MCR RJC501317-001V01 11111 C
63 10170615 SHEET/SHIELD RJC501636-001V01 11111 C
64 10163678 PLATE/CUPPER RJC501571-001V01 11111 X
65 10163680 WIRE/MCR RJC501572*001V01 11111 X
66 10163681 SCREW/BIND BITTE S-BDBT-2X8NI 22222 X
67 10307555 COVER/MCR STRAP RJC501314-002V01 11111 X
68 65140332 SHAFT/STRAP(A) C441990-001 2222222222X
69 10026079 SHAFT/STRAP(B) C444214-1 1111111111X
70 10307133 CASE/MCR LOWER RJC501313-002V01 11111 X
71 64022810 SCREW Y410078-6 4 4 4 X
C-MOS IMAGER BLOCK
72 10100243 FPC/2D RJC500527-001V01 1 1 1 1 1 1 C
73 10190101 SHEET/SHIELD RJC501758-001V01 1 1 1 1 1 1 C
74 10302840 2D MODULE IT5300SF-015RC 1 1 1 1 1 1 C
75 10307136 CASE/2D INNER RJC501325-002V01 1 1 1 1 1 1 X
76 10193309 SCREW/BIND TAP S-BDB0-2.3X4ZC 2 2 2 2 2 2 X
77 10307135 CASE/2D LOWER RJC501324-002V01 1 1 1 1 1 1 X
78 10190128 FILTER/2D RJC501323-001V02 1 1 1 1 1 1 C
79 10307139 PACKING/2D RJC501326-002V01 1 1 1 1 1 1 X
80 63292930 SCREW/FLAT HEAD A44793-13 6 6 6 6 X
INSULATION SHEET
81 10219455 INSULATION SHEET/2D RJC502274-001V01 1 1 1 1 1 1 C
82 10288956 TAPE/CONNECTOR RJC503687-002V01 2244444222B
83 10219088 INSULATION SHEET/14P RJC502272-001V01 4 4
84 10219087 INSULATION SHEET/SB RJC502273-001V01 1 1
85 10219089 INSULATION SHEET/KEY RJC502275-001V01 1 1
86 10219086 INSULATION SHEET/SIF RJC502271-001V01 1 1 1 1 C
Part Name Descriptions
QUANTITY
N Item Part No. R
N Item Part No. Part Name
Descriptions R
QUANTITY
Descriptions R
11 11
N Item Part No. Part Name
51 10153766 1
N Item Part No. Part Name Descriptions
QUANTITY
R
1 1 1X11
QUANTITY
To Next Page
