— 13 —
B-3. Remove 12 screws.
B-4. Remove the B-case Assy Block.
B-5. Unplug the connector to the speaker.
Screws (S1)
Screws (S2)
Screws (S3)
B-CASE ASSY BLOCK
Connector (Speaker)
