— 14
—
C. Removing the Rear Display Block
C-1.
Remove eight screws.
C-2.
Remove the connector to the battery
.
Connector (Battery)
Screws (S6)
C-3.
Remove the Rear Display Block.
C-4.
Unplug the connector to the Rear Display
.
Connector (REAR DISPLA
Y)
REAR DISPLA
Y
BLOCK
16
18
Table of Contents
Table of Contents
3
Specifications
4
Machine Initialization
8
Disassembly
13
Assembly
27
Option Installation
39
Inline / Online
41
Diagnostic Operation
43
Circuit Explanation
84
Hardware Diagram
84
Error Code List
87
Error Message
87
When an Error Occurs
87
Pcb Layout
98
Circuit Diagram
102
Model : Qt-6600
122
Parts List
122
Exploded View
123
Main Pcb Block
124
Final Assy Block
128
Lcd Chassis Block
128
Rear Display Block
128
U-Case Assy Block
128
B-Case Assy Block
129
Other
129
DRAWER M Type (DL-2434/DL-2808/DL-2809/DL-2810)
130
DRAWER L Type (DL-3622)
132
DRAWER L Type (DL-3623)
134
