Casio QT-6600 Service Manual

— 45 —
7-6. Test Items
This program performs the following tests.
No Device to be checked Operation Note Page
1 Batch Test 1 1
RAM, FROM (for programming),
FROM (for hibernation),
Date/Time, Buzzer, Drawer,
Receipt
33
2 Batch Test 2 2
LCD,LCD backlight, REAR
DISPLAY, REAR DISPLAY
backlight
34
3 RAM WRITE/READ Test n011 35
4 RAM READ ONLY Test n111 35
5 FLASH ROM CLEAR Test cn212 36
6 FLASH ROM WRITE/READ Test cn012 37
7 FLASH ROM CLEAR & WRITE/READ Test cn312 38
8 FLASH ROM CHECK SUM Test n512 39
9 CF-CARD CLEAR Test n213 39
10 CF-CARD WRITE/READ Test n013 40
11 CF-CARD READ ONLY Test n113 40
12 CF-CARD CLEAR & WRITE/READ Test n313 41
13 LCD Test n021 42
14 LCD Backlight OFF Test 121 42
15 LCD Calibration Setting 221 43
16 VRAM CHECK Test n721 44
17 REAR DISPLAY Test n322 45
18 REAR DISPLAY Backlight Test cn122 46
19 REAR DISPLAY Contrast Adjustment 422 47
20 REMOTE DISPLAY Test bn023 48
21 External Printer Output Test x1x2x3nm3d 49
22 Ethernet Printer Output Test x100nm37 51
23 COM(RS232C) Test xn04d 53
24 COM (RS232C) Batch Test 40 54
25 Printing COM (RS232C) Test Result 47 55
26 Ethernet Test: bm0a51 56
27 Setting MAC (Media Access Control Address) x0951 58
28 Date/Time Setting
hhmmss0070
yymmdd0170
60
29 Date/Time Display 070 60
30 Drawer Test xn091 61
31 Buzzer Test n092 62
32 MCR Test 96 63
33 Sound Test axn097 64
34 Microphone Test 98 64
35 Charge Mode Test 99 65
36 OBR Test 95 65
37 PS/2 Keyboard Test r1n094 66
