— 49 —

[ 5 ] FLASH ROM CLEAR Test

[Function]

Tests whether FLASH ROM Clear erases the memory correctly.

After this test, be sure to perform “[6] FLASH ROM WRITE/READ Test” before conducting other

tests. If other tests are performed without having conducted FLASH ROM WRITE/READ Test, the

program may be damaged and may not operate properly. Should this occur, perform all operations

starting from IPL.

[Operation]

Operation : c n 2 1 2 ST

c: Specifying FLASH ROM

0 FLASH ROM (for programming)

1 FLASH ROM (for hibernation)

n: Number of times

0 or no value To perform a single test

A value other than 0 (1 ~ 9) Tests repeat inﬁnitely (press ESC to terminate)

[LCD] [PRINT]

FLASH ROM (for programming)

FLASH 0n212

FLASH CLR OK

END 0n212

FLASH 0n212

FLASH CLR OK

END 0n212

* If the test ends with errors, the line number

and the address are printed instead of OK

message.

FLASH ROM (for hibernation)

FLASH hib 1n212

FLASH hib CLR OK

END 1n212
