— 55 —
[ 13 ] LCD Test
[Function]
Tests whether LCD operates correctly.
When performing a single test:
To change the screen, touch any part of the panel.
In order to complete the test, the operator must determine pass(OK)/fail(NG) of the result.
When performing test infinitely:
The screens change automatically.
Press ESC to end the test.
Green Blue
Reverse
check
RedWhiteBlack
Check (black
and white)
[Operation]
Operation : n 0 2 1 ST
n: Number of times
0 or no value To perform a single test
A value other than 0 (1 ~ 9) Tests repeat infinitely (press ESC to terminate)
[LCD] [PRINT]
LCD n021
Please Hit Key OK−>1 NG−>9
LCD OK
END n021
LCD n021
LCD OK
END n021
[ 14 ] LCD Backlight OFF Test
[Function]
Tests whether LCD Backlight turns OFF properly.
In order to complete the test, the operator must determine pass(OK)/fail(NG) of the result.
The backlight is set to OFF after the test. Touch any part of the Touch Panel and determine
pass(OK)/fail(NG) of the result.
(1) LCD Backlight turns OFF
(2) Touch any part of the panel
(3) LCD Backlight turns ON
(4) The operator determines pass(OK)/fail(NG) of the test result
[Operation]
Operation : 1 2 1 ST
[LCD] [PRINT]
LCD BACK LIGHT 121
Please Hit Key OK−>1 NG−>9
LCD BACK LIGHT OK
END 121
LCD BACK LIGHT 121
LCD BACK LIGHT OK
END 121
