— 62 —
[ 20 ] REMOTE DISPLAY Test:
[Function]
Tests whether the data is correctly displayed on REMOTE DISPLAY.
Be sure to connect REMOTE DISPLAY to COM3. When changing the baud rate, be sure to also
change the settings on REMOTE DISPLAY. The backlight turns on in pastel green (green + white)
when performing the test and turns off when the test ends.
When performing a single test:
In order to complete the test, the operator must determine pass(OK)/fail(NG) of the result.
After the operator determines pass(OK)/fail(NG), the display and the backlight turn off.
When repeating the test infinitely:
Repeats transmitting the same test text at a set interval.
Press [ESC] to terminate the test, clear the display, and turn off the backlight.
[Operation]
Operation : b n 0 2 3 ST
b:Specifying the baud rate
0 19.2 Kbps
1 9600 bps
n: Number of times
0 or no value To perform a single test
A value other than 0 (1 ~ 9) Tests repeat infinitely (press ESC to terminate)
[LCD]
REMOTE DISP bn023
Please Hit Key OK−>1 NG−>9
REMOTE DISP OK
END bn023
[PRINT] [REMOTE DISPLAY]
REMOTE DISP bn023
REMOTE DISP OK
END bn023
ABCDEFGHIJKLMNOP
QRSTUVWXYZabcdef
0,1,2,3,4,5,6,7,8,9,
