— 71 —
a: Transmitting/receiving mode
0 TCP transmitting mode
1 TCP receiving mode
5 Ping transmission
Transmitting and receiving continue unless an error occurs.
Press ESC to terminate the test. (To terminate the test, operate at the transmitting end.)
<Ping transmission>
Ping is sent to 192.168.0.10. When a ping is transmitted, the counter adds a value. After
terminating it with ESC key, the number of successful/failed communication is displayed.
[LCD]
ETHERNET bm0a51
TCP MODE
OK xxxx NG xxxx
END bm0a51
[PRINT]
ETHERNET bm0a51
TCP MODE
OK xxxx NG xxxx
END bm0a51
Prints the number of successful and failed commu-
nicationupon the end of the test
