Casio WK-240 Service Manual & Parts Catalogue

WK-240
– 22 –
Y
Test Items
Pressing a test button after the diagnostic program was launched or while on the main screen enables
the corresponding test item to be tested.
Test Item Button Remarks
A. Button Check 1
B. AC Adaptor Check 3 AC adaptor
C. ROM Check 5
D. RAM Check 6
E. ROM Version Check 9
F. Model Check 9
G. LCD Check 2
H. Pedal Check RHYTHM Pedal (SP-3 or SP-20)
I. USB Check PC, USB cable
<Test Mode Main Screen>
Y
Test Procedures
A. Button Check
A-1. Press the [1] button to select the “Button Check”.

Casio WK-240 Specifications

General

Control type	Buttons
MIDI-keyboard number of keys	76 keys
Metronome	Yes
Product color	Black, Silver
Sound effects	Chorus, Reverberation
Sound effects quantity	180
Maximum polyphony (notes)	48
Music memory capacity (songs)	10
Interface	USB
Headphone outputs	1
Display type	LCD
Power source type	AC, Battery, DC
Number of batteries supported	6

Weight and Dimensions

Depth	385 mm
Width	1161 mm
Height	134 mm
Weight	6900 g
