Casio XJ-V1 User Manual

3
Contents
Useful Features and Functions ...................................... 5
Getting Ready.................................................................. 6
Setting Up the Projector.........................................................................6
Setup Precautions ....................................................................................................... 6
Connecting Projector Cables .................................................................7
Remote Controller ..................................................................................8
To load remote controller batteries .......................................................................... 9
To replace remote controller batteries ..................................................................... 9
Operating the Projector................................................ 10
Selecting the Input Source (INPUT)......................................................10
To select the input source ...................................................................................... 10
Resolution .................................................................................................................. 10
Output Image Operations.....................................................................11
To use manual keystone correction (KEYSTONE).................................................. 11
To zoom an image (D-ZOOM) ................................................................................ 11
To momentarily blank the image and mute the audio (BLANK) ............................. 11
To freeze an image (FREEZE)................................................................................. 11
To auto adjust an image (AUTO) ............................................................................ 12
To change the aspect ratio of the projected image (ASPECT)............................... 12
To adjust image brightness (FUNC) ....................................................................... 13
To change the color mode (FUNC)......................................................................... 13
Adjusting the Volume Level (VOLUME) ................................................14
To adjust the volume level...................................................................................... 14
To mute the audio .................................................................................................. 14
Eco Mode (ECO)...................................................................................15
To select the Eco Mode ......................................................................................... 15
Using the Presentation Timer (TIMER) .................................................16
To display the timer ................................................................................................ 16
To display the timer function menu........................................................................ 16
To configure timer settings..................................................................................... 17
To start a countdown timer operation .................................................................... 17
To pause the timer countdown............................................................................... 18
To resume a paused timer countdown................................................................... 18
To reset the timer to its start time .......................................................................... 18

Casio XJ-V1 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	-
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	20000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 -30 °
Focus	Manual
Offset	72 %
Throw ratio	1.54 - 1.71:1
Optical zoom	1.1 x
Focal length range	- mm
Light source type	Laser/LED hybrid
Service life of light source	20000 h
Full HD	No
Supported graphics resolutions	1200 x 1600, 1680 x 1056
AC (power) in	Yes
Composite video in	0
USB connector type	Micro-USB B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Noise level (economic mode)	35 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Power source	AC
Power consumption (standby)	0.23 W
Power consumption (typical)	150 W
Operating temperature (T-T)	5 - 35 °C
Remote control type	IR

Weight and Dimensions

Width	270 mm
Height	89 mm
Weight	2800 g
