Casio XJ-V1 User Manual

40
Using Control Commands
This section explains the commands that are used to control the projector from a computer.
Command Send Format
z See the “Command List” for details about command names and settings.
z All commands use ASCII characters and decimal format integers.
z The projector will return a question mark (?) when it is sent a command it cannot recognize. Also,
any command that attempts to set a value that is outside the applicable allowable range will be
ignored.
z If the projector is performing a process initiated by a previously sent command, a projector key
operation, or a remote controller key operation, send of the next command must wait until the
projector completes the previous process.
Communication
Protocol
Configure your computer’s serial port with the following settings.
Data Rate 19200 bps
Data Bit 8 bit
Parity None
Stop Bit 1 bit
Flow Control None
Read Command
Send this command when you want information about the current setup of the data
projector.
Send Format (<command name>?)
Receive Format (<applicable command setting range>,<current setting>)
Command Send
Example
sent from the computer to the projector.
4
returned from the projector to the computer.
Write Command
Send this command to control the data projector (power on/off, etc.) and to write data to it.
Send Format (<command name><setting value>)
Command Send
Example
sent from the computer to the projector.
4
Projector volume setting becomes 0.
(
VOL ?
)
(
0
-
30,15
)
(
VOL 0
)

Casio XJ-V1 Specifications

General

Matrix size	0.55 \
Number of colors	1.073 billion colors
Native aspect ratio	-
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	20000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 -30 °
Focus	Manual
Offset	72 %
Throw ratio	1.54 - 1.71:1
Optical zoom	1.1 x
Focal length range	- mm
Light source type	Laser/LED hybrid
Service life of light source	20000 h
Full HD	No
Supported graphics resolutions	1200 x 1600, 1680 x 1056
AC (power) in	Yes
Composite video in	0
USB connector type	Micro-USB B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	37 dB
Noise level (economic mode)	35 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Power source	AC
Power consumption (standby)	0.23 W
Power consumption (typical)	150 W
Operating temperature (T-T)	5 - 35 °C
Remote control type	IR

Weight and Dimensions

Width	270 mm
Height	89 mm
Weight	2800 g
