Operator's Manual
Serenity Pellet Stove
Figure 11: Straight Installation—Inside Vertical Rise, Horizontal Termination
oor
wall
venting pipe
fresh air inlet
heat-resistant material
Figure 10: Straight Installation--outside, through wall installation
oor
termination
wall
fresh air inlet
heat-resistant material
termination
SIMPLE STOVE VENTILATION EXAMPLES
