ILLUSTRATED PARTS BREAKDOWN
ITEM # PART # DESCRIPTION QTY.
1 12225 GASKET AUGER HOUSING HPS FEED SYSTEM 1
2 15476 COMBUSTION BLOWER REPLACEMENT KIT 1
3 16135 ASH PAN WELDMENT 1
4 16278 PANEL RIGHT REPLACEMENT KIT 1
5 16279 PANEL LEFT REPLACEMENT KIT 1
6 16280 PANEL BACK REPLACEMENT KIT 1
7 16281 TOP AND HOPPER WELDMENT LID
REPLACEMENT KIT
1
8 16282 VACUUM SWITCH REPLACEMENT KIT 1
9 16283 52C SENSOR REPLACEMENT KIT 1
10 16284 KIT HOPPER ASSEMBLY REPLACEMENT 1
11 720104 CONVECTION BLOWER REPLACEMENT KIT 1
12 720055 HOPPER LID SWITCH 1
13 720106 SENSOR TEMPERATURE 92 DEG C 1
14 720204 DOOR ASSEMBLY REPLACEMENT KIT 1
15 720207 AUGER MOTOR KIT 1
16 720216 ADJUSTABLE FOOT 4
17 720219 WELDMENT AUGER FEED SYSTEM 1
18 720220 BEARING LOWER AUGER 1
19 720221 BEARING UPPER AUGER 1
20 720227 POWER SUPPLY SWITCH REPLACEMENT KIT 1
21 720229 HOPPER HANDLE REPLACEMENT 1
22 720235 FIREPOT WELDMENT 1
23 18522 COMBUSTION MOTOR GASKET KIT 1
24 720298 CONTROL HEAD REPLACEMENT KIT 1
25 720304 INTERFACE MODULE REPLACEMENT KIT 1
26 720307 IGNITER REPLACEMENT KIT 1
27 720308 COLLAR IGNITER RETAINER REPLACEMENT KIT 1
28* 13512 LEAD, PIGTAIL, 30C 1
29* 13513 BRACKET, HOLDER 30C 1
* ITEM NOT ILLUSTRATED
