18
Operator's Manual
Serenity Pellet Stove
Vent
Clearance*
3” Min.
Outside air may be drawn from
a vented crawl space.
Floor
Protection
“L” Vent
Class A Chimney Ceiling Support
Class A chimney must
maintain clearances outlined
in the chimney’s installation
instructions (usually 2”)
Storm Collar
Roof Flashing
“L” Vent to Class A Chimney Adapter
Class A Chimney
* Install a vent at clearance specied by the vent manufacturer
CLASS A CHIMNEY RETROFIT
Figure 13: Class A Chimney Retrot
