The locking mechanism is composed of two magnets that attract each other when correctly aligned.
To lock the Transmitter unit into the Cover align the marks located at the bottom of the Transmitter
and bottom of the Cover with each other. Slide the Transmitter gently inside the opening of the Cover
until you hear a click. Test whether the locking has been successful by pulling on the Transmitter and
trying to remove it with a vertical force. If it does not come out with significant force, the magnets are
correctly aligned.
Locking the Transmitter to the Cover
Step 1 Step 2 Step 3
Always properly lock the Transmitter unit, with the attached foam cap, into
the Cover before use. Improperly locking the Transmitter, or a failed locking
mechanism, will result in the Transmitter unit coming out during use, potentially
leading to serious injury and/or property damage.
