CONTROL PANEL “PC180-ST”
DESCRIPTIONS
3) Water pump button; it controls the pump relais.
8) Button with integrated twilight sensor to set the
intensity of the LED backlighting in a "night”
1) Mains’ general button ON/OFF; LED flashing
indicates that the battery is low and that the low
voltage device will turn on.
4) Awning light button; awning light switches
automatically off when you start up the engine.
the
NOTE: at start-up, the panel verifies the
functioning of all LEDs, with the exclusion of
ref. 14 and 15.
5) Button to check the leisure battery (B2).
2) ; it controls the , 12V sockets 12V button lights
and . heating
6) Button to check the car battery (B1).
7) Button to check the water tankfresh .
situation (see also the “TWILIGHT” function).
9) If this symbol blinks the car battery (B1) has run
down.
14) It shows the leisure batterie recharging through
engine alternator.
10) If this symbol blinks the leisure battery (B2) has
run down.
11) If this symbol blinks the water tank is
empty.
fresh
12) If this symbol blinks the waste water tank is full.
13) LED display:
-Voltmeter for the control of car and leisure
battery voltage (scale 0 to 100%).
- water tank level (Emergency level, 1/3,
2/3, 3/3).
Fresh
15) Led to signal 230V net on.
EN
12
12V
9
10
12
14
1
2
3 4
11
13
15
5 76
8
