- Series 5000 Back Panel* -
1) Lid Temperature Alarm Connector - This port is used to attach an Auto-Dialer or a Remote
Alarm Monitor.
2) Level Alarm Connector - This port is used to attach an Auto-Dialer or a Remote Alarm
Monitor; This connector will give high and low level alarms, as well as power-loss alarm if
power to the unit is cut off. May also be wired in series with the Lid Temp Alarm
connector to work on the same line.
3) Fuse - 1 amp Buss fuse; 220 volts slow-blow.
4) Power Cord - This is the main power supply cord to the unit, be sure to check for proper
voltage - See voltage requirements listed on the controller.
* Design is changing - Contact factory for the latest information.
